Cleanroom Pass Box

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Cleanroom Pass Box Price And Quantity

Minimum Order Quantity 1 Unit

Cleanroom Pass Box Trade Information

Payment Terms Cash Against Delivery (CAD) Cash in Advance (CID)
Supply Ability Depend on Order Per Month
Delivery Time 20 Days
Main Export Market(s) Australia Central America South America Eastern Europe Western Europe Middle East Africa Asia North America
Main Domestic Market All India

Product Description

We are the leading manufacturer and supplier of Cleanroom Pass Box, that is very effective used for its quality and durability. It is utilized for exchange of material starting with one zone then onto the next with disconnection by method for Mechanical & Electromagnetic entryway interlocking, which guarantees opening of just a single entryway at once. Consequently staying away from cross defilement between two area's. Also, this Clean room Pass Box can be availed in various specifications at ,market leading rates.

Cleanroom Dynamic Pass Box /Static Pass Box

DESCRIPTION : It is used for transfer of material from one area to another with isolation by means of Mechanical / Electromagnetic door interlocking, which ensures opening of only one door at a time. Thus avoiding cross contamination between two area's.

CONSTRUCTION : These units are factory assembled and are made up of S. S. 304 grade Stainless Steel material. These units have smooth welded corners.

INSTALLATION : Pass-Through Chambers can be installed in a number of ways, depending on the wall or door that will support them.

General Specification of the Dynamic Pass Box:

MOC	SS 304, SS316.
Pre-filter	Air Micron Make EU 4 rating with suitable size having efficiency 90% down to 10 micron.
Final Supply Filter	HEPA Filter having EU 13 or EU14 rating with suitable size having efficiency 99.997& down to 0.3 micron.
Motor Blower Assembly	Statically & Dynamically balanced with suitable rating and size. (Induction motor with centrifugal blower) A Mounting unique spring suspension system to take care of vibration and noise.
Differential Pressure Gauge	(make : Dwyer, USA) (To measure differential pressure across the supply HEPA filter
Lights	CFL Light Through Clear Acrylic to Get Maximum Illumination / Hour Meter with UV Light.
Door Interlocking	Electro Magnetic Interlocking
Air Cleanliness	Class ISO 5 (as per ISO 14644-1).
Air Flow Rate	0.45 + 0.1m/sec.
Vibration Level	Minimum

General Specification of the Static Pass Box

MOC	SS 304, SS 316
Doors	Sandwiched Door with double sided View Panel, Handles
Door Interlocking	Electro Magnetic Interlocking
Coving	Inner Side Bottom Corners will be Duly Coved.
Protective Light	UV light with hour meter.

Air Micron Cleantech Clean room Pass Box with Laminar Air Flow
Model	Bioclean storage space dimensions			Overall dimensions
Model	w	d	H	W	D	H
2610-SP-LF	1220	1220	1220	1470	1370	2000
2610-SP-LF-1	910	610	910	1100	680	1560
2610-SP-LF-2	610	610	610	790	680	1260
